Why Choose Radik?

The Radik Delta 3D Printer is a reliable and affordable professional-grade 3D printer, built with industrial-level components and featuring our new one-of-a-kind extrusion technology.

Very unique patent technology: Delta Direct Extruder (DDE) for best filament control.

Constructed from ALL industrial-grade CNC machined parts. No plastic and printed part.

Simple and efficient modular design. Easier for  service and upgrade.

Rigid and custom-built aluminum extrusion frame. Stable at high printing speed.



RADIK

Delta 3D Printer

A reliable and affordable desktop 3D printer fit for Small Businesses and Professional makers

Radik Delta 3D Printer

Delta Direct Extruder (DDE): Our unique patent 3D printing technology

The Radik Delta 3D printer utilizes our patent Delta Direct Extruder (DDE) technology, a direct extruder system that uses a remotely located extruder motor, using a solid bar linkage and universal joins, keeping the printhead light while minimizing filament errors. The printer takes the advantages of both the Bowden and Direct extruders, while leaving all of the negatives behind.

Our patent DDE technology is the first ‘direct extruder’ filament control system ever used on a Delta 3D printer.

Dual Nozzle Dual Extruder

Use disolvable support material or set dual colors print

Heated Bed

Using High Power heating element for stronger and quick temperature control



Direct Drive Extruder

Highest response filament control



Fully Enclosed

Maintance temperature during critical printing process

All Metal Print-Head

Optimal maximum temperature that open to wider range print material

Open Source Firmware

Maker-friendly by using open source firmware for future custom setting



Dual Nozzle Dual Extruder

Use disolvable support material or set dual colors print

Heated Bed

Using High Power heating element for stronger and quick temperature control



Direct Drive Extruder

Highest response filament control



Fully Enclosed

Maintance temperature during critical printing process

All Metal Print-Head

Optimal maximum temperature that open to wider range print material

Open Source Firmware

Maker-friendly by using open source firmware for future custom setting



Meet All Important Radik's Features

Direct Drive Extruder

The most precise and responsive filament control system on the market, optimizing material retraction and printing process

All-Metal Printhead

All-metal printhead enables temperatures of up to 300’C, and is compatible with a wide range of filament types, including PLA, ABS, Nylon, PVA, and more

All CNC Machined Parts

Every single component is produced from CNC machining, creating an industrial-grade system with unbeatable quality

Slick Custom AL Extrusion

Our rigid and robust extrusion system enables optimized stability during high speed printing process

Low Operating Cost

Compatible with almost any brand or type of filament on the 3D printing market

Full Enclosed

Full enclosure promotes stable temperatures during the printing process, a key aspect to getting the highest quality print

Engineered With Modular Design

Easier to build leads to a robust design and print reliablity by having 4 main assemblies only.

Bed Leveling Assistance

Automated system helps set optimal level for first layer of printing

Filaments Kept Inside*

Maintain humidity levels by storing filament inside of the temperature controlled print chamber, optimizing the quality of filament and final prints (*for small size spool)

LCD Touchscreen

Intuitive interface enables stand-alone 3D printing via USB drive, no computer needed

Maker Friendly

Open source Marlin firmware and Simplify3D slicing engine offers makers full control over the system

Design for Serviceability

Radik Delta 3D Printers has been carefully engineered to be easier and quicker for fixing, service and upgrade

TECHNICAL SPECIFICATIONS

Printer Dimensions

Printable area: round 180mm (for Dual nozzle/head)
Printable height: 140mm
Footprint: 500x450x600mm
Weight: 20 kg

Printing

​Dual Nozzles
FFF Technology
Bed Leveling Assistance
Nozzle size: 0.4mm
Full Metal Nozzle
Default Resolution: 150 microns
Filament Diameter: 1.75mm
Max nozzle temp.: 300'C
Max bed temp.: 120'C

Material Filaments

ABS
PLA
NYLON
PVA



Software

Simplify3D
File: STL
Firmware Marlin
Connectivity: USB cable or
USB Drive for stand alone printing

Electrical

AC input: 100v-120v
600W



MODULAR-DESIGN

SMART ENGINEERING

Easy to Build leads Easy to Maintance equals Higher Uptime

1. VERTICAL LINERAR RAIL

2. ELECTRONIC BOX

3. HEATED BED

4. PRINTHEAD
